no need pallet QTM 6-24 Egg layer moving hollow block machine
QTM6-24 Movable Concrete Block Making Machine
Low investment: high efficiency: this machine have several function features, such as low price,reliable performance, easy to operated, stable, more efficient, high output, low power consumption.the brick it produced have high density, high strength, accurate dimensional, good appearance,so it can reduce the customer's investment and production costs and give fast and large benefit.
QTM6-24 Movable Concrete Block Making Machine Technical Parameters
400* 200* 200mm
400* 150* 200mm
400* 100* 200mm
1800* 1800* 1500mm
Hydraulic Pressing+ Vibration Molding
Automatic Moving and Hydraulic Steering
Mainframe Motor Power
No Need For Pallets
QTM6-24 movable concrete block making machine is one of our best selling egg laying block making machine.
1. Motor: The motor for the host machine is Germany SIEMENS brand;
2. Switch: France Schneider brand and Japan Omron;
3. Mould: Newest heat treatment and carburizing treatment assure a longer mould lifespan and ensure the strength of mold reach to 54-58 HRC so that the mould can be used about 150000 times;
4. Machine Frame and welding: All materials and spare parts selected according to international CE standard, Carbon dioxide protection welding assure a whole line stable running;
5. No need pallets: Save the pallets investment cost.
Name: QTM6-24 Movable Concrete Block Making Machine
The production capacity depends on this forming machine and it is also the essential part of the whole production line. You can change moulds on this parts to make different shapes of blocks, bricks, pavers and curbstones.
• The electricity motor for host machine we use Germany Siemens motor, for other parts, we use CE motor.
• About the switches, we will use France Schneider or China CHNT.
• Rakes in several rows make sure raw materials fed well-distributed.
• Hydraulic components we use Taiwan JiuGang famous brands.
• The demolding synchronizer avoids the damage to concrete products.
• The vibration system contain two part, one is up-mould vibration box, it is electricity motor to supply the power for up-mould vibration box. And the down mould, there is one big vibration. When the scatter material work is finished, the hydraulic power with the two vibration power will assure the good quality for product.
• Heavy duty machine structure and wear resistant moulds are processed with carburizing, nitriding, wolfram carbide and quenching which ensures its strength reach to 54~58 HRC and can be used 100 thousand times. Greatly improves the using lifetime of the machine by 50%.
• Use Frequency Conversional Control Technology, which controls the block making:
1. Frequency Conversion Control: guarantees the precise and parallel movement between tamper head and mould, protects the products
from transfiguration; increases the production rate by improving the vibrating efficiency;
2. Controls the instantaneous start and stop of the motors, to protect the motor from over-heating caused by constant working;
3. Power saving: 30%.
• Use Double high-dynamic Proportional/Directional Valves to automatically adjust the oil flow and pressure
1.Buffer the hydraulic cylinder, to protect the cylinder from damage caused by inertia;
2.Guarantee production stability.
• 360° Multi-Shaft Rotating and Compulsory Feeding:
1. Speedy and rotating feeding, with uniform mixing, to make sure that the density and intensity of the products are guaranteed;
2. This uniform feeding is applicable for different kinds of raw materials and moulds.
Name: JS500 Horizontal Double Shaft Concrete Mixer
Before using, connecting to the power source (according to the local power source requirement). Put 8kgs machine oil into gear case. Then, make the machine work for 5 minutes without anything. The next step, put the material (granules and glue) into the container. It takes 5-6 minutes to finish the mixing. After using, please clean the container.
