QT5-15 Germany technical automatic concrete block making machine concrete block machinery

  1. It is a compact machine with electric and hydraulic system, each procedure action locks with each other to guarantee the machine operate safely, easily and dependablely.
  2. Through mold-releasing oil cyclinder, the mold box was locked into the vibration table with high rigidity to reach the synchronous vibration, so that the concrete can be fluidified and exhausted in two or three seconds to ensure the high-density, especially suitable to produce the standard blocks, which can be piled up immediately so that the pallet investment can be saved directly.
  3. The unique forcing charge system can make use of various kinds of industrial waster and material such as coal ash, cement, sand, stone, slag, and so on. The machine can severs several purposes and produce various specification standard bricks, concrete blocks, porous blocks, paving bricks etc.

 QT5-15 germany technical automatic concrete block making machine concrete block making machinery

QT5-15 Germany technical automatic Concrete Block Making Machine productivity

Item size(mm Qty/mould Cycle molding Per hour
hollow block 400*200*200 5pcs 15~20s 900-1200pcs
Solid brick 240*115*53 32pcs 13~15s 7680-8800pcs
zigzag paver  225*112.5*60 16pcs 13~15s 2880pcs
holland paver 200*100*60 18pcs 20s 3240pcs
I type paver 200*160*60 15pcs 20s 2700pcs



QT5-15 Germany technical automatic concrete block making machine main technical parameter

Main Technical Specifications

Overall Dimension

7400×1950×2700(mm)

Rated pressure

21MPa

Main vibration form

Platform vibration

Cycle Time

15-20 seconds

Vibrating Frequency

2800-4500rolls/minute

Motors Power

32KW

Pallet Size

1100*570(mm)

Exciting force

60KN

Mould Material

Q345 STEEL equal to European S355 ,And treated by heat,all of paver bricks adopt wire cutting technical

Machine Material

National Standard Steel Q235

Thickness of Machine

Between 5MM-20MM. Different part the thickness is different

Raw Materials

crushed stone, sand, cement, dust and coal fly ash, cinder, slag, gangue, gravel, perlite, and other industrial wastes.

Motors& PLC &Hydraulic

Motor and PLC from Siemens, Hydraulic from  Taiwan Calyca, Frequency Converter from Rexroth Germany

Applied Products

concrete blocks, solid/hollow/cellular masonry products, paving stones with or without face mix, garden and landscaping products, slabs, edgers, kerbstones, grass blocks, slope blocks, interlocking blocks, etc.

 QT5-15 germany technical automatic concrete block making machine concrete block making machinery



1. Area: Workshop area: 150m2, all factory area 3000m2, the bigger, the better.

2. Workers :  4-5 workers can operate

3. Ratio of raw material:cement 8%-10% sand 30%-40% stone:50%-60%,about cement :sand : stone is1:4:5.

4.hollow block weight::

                                (400*200*200) :17KG

                                (200*140*200):13.5KG

                                (400*90*200):10KG

5. raw material consumption per day:150-190T

6. water consumption per day:3%-5% of raw material Weight.



Here show some main parts information as below

Hydraulic system 1. we use Taiwan Cylyca hydraulic valve and paddle pump

                                           2. Double proportional valve design can adjust both oil pressure and flow automaticlly

                                           3. Water cooling system ensure oil temperater lower than 60 degree

QT5-15 germany technical automatic concrete block making machine concrete block making machineryQT5-15 germany technical automatic concrete block making machine concrete block making machinery

Vibration system 1. for the vibration system, we use eccentric blocks and synchronization gears to make sure high                                                          vibration force ad less electricity power consumption

                            2.vibration box is using casting material, in case of oil leakage.

                                           3. using frequency motor make the vibration platform high frequency and lower amplitude, so the                                                         platform vibration is more stable and lower noise

                                          4. the syncronization gears use 45# steel and processed by heat treatment .

QT5-15 germany technical automatic concrete block making machine concrete block making machinery



Feeding system 1.feeding teeth is Q235 manganese steel and can use long life-time

                                         2. the assembled feeding teeth can 360 degree rotating  will re-mix the raw material evenly and be easy                                                  to  maintain

                                        3.feeding box  adopt double  pulleys and pressing spring to prevent from scattering materials



QT5-15 germany technical automatic concrete block making machine concrete block making machinery

 Control system  1. Siemens 7" color touching screen

                                    2.Siemens PLC

                                    3. Artificial intelligence interface design

                                    4. convenient -type aviation plug , easy to install the electric system and hydraulic system

                                    5. there is frequency conveter in PLC control box . it can protect th motors from unstable voltage.

                                    6.all of electric components from Schneider
