low price hot sale QT3-20 Paver making machine in Africa
Product Description
Product Description
QT3-20 Automatic/Semi-automatic Concrete Block Making Machine
Model QT3-20 Automatic/Semi-automatic concrete block forming machine is developed and manufactured on the basis of the original block forming machine and through technological innovation. It has reasonable design and excellent performance. It's equipped with strong vibration motor. The block has good quality, high density and strength. The machine adopts upper die(mould) push-pull, directly and fast scraping, convenient and easy operation, and its performance can be comparable to some big machine.
QT3-20 Automatic/Semi-automatic Concrete Block Making Machine Technical Parameters | ||||||||
No. | Size (L*W*H) | Pieces/Mould | Pcs/Hour | Pcs/Shift | ||||
1 | 400* 200* 200mm | 3 | 430- 540 | 3440- 4320 | ||||
2 | 200* 100* 60mm | 10 | 1500 | 12000 | ||||
3 | 200* 163* 60mm | 3 | 450 | 3600 | ||||
Mainframe Dimension | 5990* 4260* 2620mm | |||||||
Weight of Host Machine | 3 Tons | |||||||
Pallet Size | 680* 550* 22mm | |||||||
Vibration Method | Hydraulic+ Vibration Platform | |||||||
Moulding Period | 15- 20 Seconds | |||||||
Water Consumption | 4- 5 Tons/Day | |||||||
Vibration Force | 40- 50KN | |||||||
Workshop Area | 100- 150m2 | |||||||
Total Machine Power | 20.35KW | |||||||
Main Features
1. Low price, saving cost, simple and fast installation, after six months of investment and operation, business can be profitable, best choice for small and medium factories.
2. Saving more electric power than traditional brick/block making machine.
3. Can meet different production requirements by changing mould, we provide various mould for hollow bricks, solid bricks, paving bricks, curbstones and etc, brick size and shape can be customized.
4. Bricks don't need to go through fire process, special kilns and chimneys are not needed, energy and production space are saved, environment is protected and pollution is avoided.
5. Minimum 2 workers and 160 square meters of land are needed to meet the production requirements.
6. Easy operation and maintenance.
7. The bricks can meet the requirements of various types of buildings and roads.
8. It can work in different seasons and environments. With proper operation and maintenance, the service life of the machine can reach 15-20 years.
Detailed Images
Mainframe
Name: QT3-20 Automatic/Semi-automatic Concrete Block Making machine
Brand: KAIDONG
Original: China
The production capacity depends on this forming machine and it is also the essential part of the whole production line. You can change moulds on this parts to make different shapes of blocks, bricks, colored pavers and curbstone.
This machine equips color feeding system with the mainframe and cannot be seperated, that's why this type is a litte bit expensive than some familiar machines. If you want to produce both normal bricks or block and colored pavers, but don't have too much budget, this one will be your best choice.
Mixer
Name: JQ500 Vertical Concrete Mixer
Brand: KAIDONG
Original: China
Before using, connecting to the power source (according to the local power source requirement). Put 8kgs machine oil into gear case. Then, make the machine work for 5 minutes without anything. The next step, put the material (granules and glue) into the container. It takes 5-6 minutes to finish the mixing. After using, please clean the container.
Global Vision
Certifications
Our Factory
KAIDONG MACHINERY
SHANDONG KAIDONG CONSTRUCTION MACHINERY CO.,LTD(SHANDONG KAIQIAN IMPORT & EXPORT CO.,LTD) are professional building materials machinery and equipment research, manufacture and export company. Company business started in 1998, year turnover is more than 50 million USD. The company's main products are concrete block making machine, AAC block machine, concrete pole pipe making machine, concrete roof tile machine and mixer.
The company passed ISO9001 management system and the European Union CE certification, the products absorb the German mechanical design and manufacturing experience, focus on quality design, high-quality material, exquisite welding and strict inspection process to ensure high-quality equipment and maximize service life. Company products are exported to Southeast Asia, Africa, South America, Eastern Europe, the Middle East, Australia and more than 90 countries and regions.
Company of "integrity first, win-win cooperation", the positive development of quality products, improve the quality of service. We are not only the machinery products supplier, most important is that we are best program and service supplier according to clients real conditions. Welcome all customers to cooperate with us.
